Achieve High-Speed Double Layer Wire Stripping with the YHT3 Machine: Precision & Efficiency for Round Sheathed Cables
Introduction:
Introducing the Wire Range 2-7mm YHT3 Double Layer Stripping Machine, a high-performance solution meticulously engineered to revolutionize your wire processing workflow. This advanced Wire Stripping Peeling Cutting Machine is specifically designed for high-speed and precise stripping of round sheathed cables, effortlessly handling both inner and outer layers with exceptional accuracy. The WPM-YHT3 Double Layer Stripping Machine, also known as a High-Speed Round Sheath Double Layer Peeling Tool, is designed to boost your productivity and streamline your wire preparation processes. Experience user-friendly touch screen operation, high precision length accuracy, and versatile wire handling capabilities with this indispensable machine for modern wire processing demands. (Please note: Wire collecting board and protection cover are optional and not included as standard. Please contact the seller if you require these additions.)
Key Features and Benefits:
- High-Speed Round Sheath Inner and Outer Double Layer Peeling Capability: This Double layer stripping machine excels at high-speed stripping of both the inner and outer layers of round sheathed cables simultaneously. Significantly reduce processing time and boost your production output compared to single-layer or manual stripping methods.
- Wide Wire Range Compatibility for Diverse Applications (2-7mm Round Sheath Wire): Designed to handle a versatile wire range of 2-7mm diameter round sheath wires. This Wire Stripping Peeling Cutting Machine is suitable for a broad spectrum of cable sizes and applications.
- Touch Screen Operation Interface for Intuitive Control and Easy Setup: Features a user-friendly 4.3-inch touch screen display with Chinese and English switching. Enjoy intuitive operation, easy parameter setting, and streamlined workflow management with this advanced control interface.
- High Precision Length Accuracy for Consistent and Reliable Wire Preparation: Achieve exceptional length accuracy with a tolerance of ± 0.2mm. Ensure consistent and reliable wire preparation, minimizing errors and material waste in your production process.
- Versatile Processing of Multi-Core Wires (2, 3, 4 Cores): This Double layer stripping machine is capable of processing 2-core, 3-core, and 4-core wires, offering versatility to handle various cable configurations and project requirements.
- Forward and Reverse Straightener for Improved Wire Feeding and Processing: Equipped with a forward and reverse straightener, this machine ensures smooth and controlled wire feeding, improving processing accuracy and overall efficiency.
- Optional Protective Cover for Enhanced Operator Safety (Optional – Not Included Standard): A protective cover is available as an optional add-on to enhance operator safety during machine operation. (Please note this is not included as standard and must be requested separately).
- Disconnection Device Integrated for Streamlined Wire Handling: Features an integrated disconnection device to facilitate smooth wire handling and processing, further enhancing efficiency and workflow.
- Four-Wheel Drive System for Stable and Reliable Wire Transport: Utilizes a four-wheel drive system powered by a silent hybrid stepper motor, advancing 0.1mm per step. This robust drive system ensures stable and reliable wire transport, minimizing slippage and maximizing processing accuracy.
- Adjustable Outer Wire Strip Lengths (Front & Rear End: 1-150mm): Offers adjustable outer wire strip lengths for both the front and rear ends, ranging from 1-150mm. Customize stripping dimensions to meet specific project and connection requirements.
- High-Speed Steel Blade for Durable and Precise Cutting and Stripping: Equipped with a high-speed steel blade ensuring durable and precise cutting and stripping performance for long-lasting operation and consistently high-quality results.
Technical Specifications:
| Feature | Specification |
|---|---|
| Product Type | Double Layer Stripping Machine |
| Keyword Focus | double layer stripping machine |
| Also Known As | Wire Stripping Peeling Cutting Machine, High-Speed Round Sheath Double Layer Peeling Tool |
| Model | WPM-YHT3 |
| Wire Type | Round Sheath Wire |
| Wire Range (Diameter) | ￠2-7mm |
| Number of Cores | 2 Cores, 3 Cores, 4 Cores |
| Operation Interface | 4.3 inch Touch Screen (Chinese/English) |
| Voltage | 110V/220V 50HZ/60HZ |
| Power Consumption | 300W |
| Weight | 38KG |
| Dimension | 450420335mm |
| Air Pressure | 0.8Mpa |
| Length Accuracy | ± 0.2mm |
| Max Conduit Inside Diameter | ￠9mm |
| Wire Length Range | Max 9999mm |
| Outer Wire Strip Length (Front End) | 1-150mm |
| Outer Wire Strip Length (Rear End) | 1-150mm |
| Blade Material | High-Speed Steel |
| Transport Speed | 2000-3000 pieces/hour (L=200MM) |
| Driving Mode | Four-Wheel Drive (Silent Hybrid Stepper Motor) |
| Special Features | Double Layer Stripping, High-Speed, Forward/Reverse Straightener, Optional Protective Cover, Disconnection Device |
